| Input Voltage |
7.4–25.2 V (2S–6S) |
7.4–25.2 V (2S–6S) |
7.4–25.2 V (2S–6S) |
| Storage |
microSD card slot, up to 256 GB |
microSD card slot, up to 256 GB |
microSD card slot, up to 256 GB |
| Transmit Power (EIRP) |
FCC/SRRC: <30 dBm, CE: <14 dBm |
FCC/SRRC: <30 dBm, CE: <14 dBm |
FCC/SRRC: <30 dBm, CE: <14 dBm |
| Ports |
microSD card slot; DC5521 power input; 3.5 mm head-tracking port |
microSD card slot; standard HDMI; USB-C; DC5521 power input; JST SH 1.0 6-pin UART port |
microSD card slot; standard HDMI; USB-C; DC5521 power input; JST SH 1.0 6-pin UART port |
| Display Type |
LCD |
— |
— |
| FOV |
58° |
— |
— |
| Display Size |
4.5 inch |
— |
— |
| Video Output Resolution |
1080p/50/60 fps; 720p/50/60 fps |
1080p/50/60 fps; 720p/50/60/100/120 fps |
2.7K/50/60 fps; 1080p/50/60/100/120 fps; 720p/50/60/100/120 fps |
| Passthrough / Telemetry |
— |
Yes |
Yes |
| UVC Support |
— |
— |
Yes |
| Audio Transmission |
— |
— |
Yes |
| OSD Recording |
— |
— |
Yes |
| Video Transmission Bitrate |
Up to 25 Mbps |
Up to 25 Mbps |
Up to 25 Mbps |
| Transmission Latency |
45 ms average |
35 ms average |
35 ms average |
| Number of Antennas |
2 |
2 |
2 |
| Antenna Gain |
Built-in Patch Antenna: 4.9 dBi |
Redbird Antenna: 1.9 dBi |
Redbird Pro Antenna: 2.8 dBi |
| Weight |
350 g |
118 g |
140 g |
| Antenna Polarization |
LHCP |
LHCP |
LHCP |
| Transmission Range |
>8 km |
>6 km |
>8 km |
| Channels |
3 |
3 |
3 |
